Product ID: TDS-242
Fusion Pro® the original stain proof, color perfect grout.* This professional grade sanded grout features unsurpassed stain resistance with no sealing required. Its Single Component® formula is ready to use and easy to spread and clean. Fusion Pro can be installed in commercial and residential environments, interiors and exteriors, and on walls and floors and specifically shower floors. Its patented formulation can be applied on all tiles and has built-in Microban antimicrobial product protection. *See warranty for details.
1 gallon pail of Fusion Pro Grout in ft² (m²) per gallon
| Tile Size | Joint Width | |||||
| Width x Length x Thickness | 1/16" (1.6 mm) | 1/8" (3 mm) | 3/16" (4.8 mm) | 1/4" (6.3 mm) | 3/8" (9.5 mm) | 1/2" (13 mm) |
| 1" x 1" x 1/4" (2.5 x 2.5 x .64 cm) | 55 ft² (5.1 m²) | 31 ft² (2.9 m²) | 23 ft² (2.1 m²) | 19 ft² (1.8 m²) | 15 ft² (1.4 m²) | 14 ft² (1.3 m²) |
| 2" x 2" x 1/4" (5 x 5 x .64 cm) | 103 ft² (9.6 m²) | 55 ft² (5.1 m²) | 39 ft² (3.6 m²) | 31 ft² (2.9 m²) | 23 ft² (2.1 m²) | 19 ft² (1.8 m²) |
| 3" x 3" x 1/4" (7.6 x 7.6 x .64 cm) | 152 ft² (14.1 m²) | 79 ft² (7.3 m²) | 55 ft² (5.1 m²) | 43 ft² (4 m²) | 31 ft² (2.9 m²) | 25 ft² (2.3 m²) |
| 4.25" x 4.25" x 1/4" (10.8 x 10.8 x .64 cm) | 213 ft² (19.8 m²) | 110 ft² (10.2 m²) | 75 ft² (7.0 m²) | 58 ft² (5.4 m²) | 41 ft² (3.8 m²) | 32 ft² (3.0 m²) |
| 6" x 6" x 1/4" (15.2 x 15.2 x .64 cm) | 298 ft² (27.7 m²) | 152 ft² (14.1 m²) | 103 ft² (9.6 m²) | 79 ft² (7.4 m²) | 55 ft² (5.1 m²) | 43 ft² (4.0 m²) |
| 8" x 8" x 3/8" (20.3 x 20.3 x 1 cm) | 263 ft² (24.4 m²) | 134 ft² (12.4 m²) | 91 ft² (8.5 m²) | 69 ft² (6.4 m²) | 47 ft² (4.4 m²) | 37 ft² (3.4 m²) |
| 12" x 12" x 3/8" (30.5 x 30.5 x 1 cm) | 393 ft² (36.5 m²) | 199 ft² (18.5 m²) | 134 ft² (12.4 m²) | 101 ft² (9.4 m²) | 69 ft² (6.4 m²) | 53 ft² (4.9 m²) |
| 16" x 16" x 3/8" (40.6 x 40.6 x 1 cm) | 523 ft² (48.6 m²) | 263 ft² (24.4 m²) | 177 ft² (16.4 m²) | 134 ft² (12.4 m²) | 91 ft² (8.5 m²) | 69 ft² (6.4 m²) |
| 18" x 18" x 3/8" (45.7 x 45.7 x 1 cm) | 588 ft² (54.6 m²) | 296 ft² (27.5 m²) | 199 ft² (18.5 m²) | 150 ft² (13.9 m²) | 101 ft² (9.4 m²) | 77 ft² (7.2 m²) |
| 20" x 20" x 3/8" (50.8 x 50.8 x 1 cm) | 653 ft² (60.7 m²) | 328 ft² (30.5 m²) | 220 ft² (20.4 m²) | 166 ft² (15.4 m²) | 112 ft² (10.4 m²) | 85 ft² (7.9 m²) |
| 24" x 24" x 3/8" (61 x 61 x 1 cm) | 782 ft² (72.6 m²) | 393 ft² (36.5 m²) | 263 ft² (24.4 m²) | 199 ft² (18.5 m²) | 134 ft² (12.4 m²) | 101 ft² (9.4 m²) |
| 6" x 24" x 3/8" (15.2 x 61 x 1 cm) | 315 ft² (29.3 m²) | 160 ft² (14.8 m²) | 108 ft² (10 m²) | 82 ft² (7.6 m²) | 56 ft² (5.2 m²) | 43 ft² (4.0 m²) |
| 12" x 24" x 3/8" (30.5 x 61 x 1 cm) | 523 ft² (48.6 m²) | 263 ft² (24.5 m²) | 177 ft² (16.4 m²) | 134 ft² (12.4 m²) | 91 ft² (8.4 m²) | 69 ft² (6.4 m²) |
| 6" x 36" x 3/8" (15.2 x 91.4 x 1 cm) | 338 ft² (31.4 m²) | 171 ft² (15.9 m²) | 115 ft² (10.7 m²) | 87 ft² (8.1 m²) | 60 ft² (5.6 m²) | 46 ft² (4.3 m²) |
| 9 x 36" x 3/8" (22.9 x 91.4 x 1 cm) | 471 ft² (43.8 m²) | 238 ft² (22.1 m²) | 160 ft² (14.9 m²) | 121 ft² (11.2 m²) | 82 ft² (7.6 m²) | 62 ft² (5.8 m²) |
| 12" x 48" x 3/8" (30.5 x 122 x 1 cm) | 627 ft² (58.2 m²) | 315 ft² (29.3 m²) | 212 ft² (19.7 m²) | 160 ft² (14.9 m²) | 108 ft² (10 m²) | 82 ft² (7.6 m²) |
1 quart pail of Fusion Pro Grout in ft² (m²) per quart
| Tile Size | Joint Width | |||||
| Width x Length x Thickness | 1/16" (1.6 mm) | 1/8" (3 mm) | 3/16" (4.8 mm) | 1/4" (6.3 mm) | 3/8" (9.5 mm) | 1/2" (13 mm) |
| 1" x 1" x 1/4" (2.5 x 2.5 x .64 cm) | 14 ft² (1.3 m²) | 8 ft² (0.7 m²) | 6 ft² (0.5 m²) | 5 ft² (0.4 m²) | 4 ft² (0.4 m²) | 3 ft² (0.3 m²) |
| 2" x 2" x 1/4" (5 x 5 x .64 cm) | 26 ft² (2.4 m²) | 14 ft² (1.3 m²) | 10 ft² (0.9 m²) | 8 ft² (0.7 m²) | 6 ft² (0.5 m²) | 5 ft² (0.4 m²) |
| 3" x 3" x 1/4" (7.6 x 7.6 x .64 cm) | 38 ft² (3.5 m²) | 20 ft² (1.8 m²) | 13.8 ft² (1.3 m²) | 10.8 ft² (1 m²) | 7.8 ft² (0.7 m²) | 6.3 ft² (0.6 m²) |
| 4.25" x 4.25" x 1/4" (10.8 x 10.8 x .64 cm) | 53 ft² (4.9 m²) | 28 ft² (2.5 m²) | 19 ft² (1.7 m²) | 14 ft² (1.3 m²) | 10 ft² (0.9 m²) | 8 ft² (0.7 m²) |
| 6" x 6" x 1/4" (15.2 x 15.2 x .64 cm) | 74 ft² (6.9 m²) | 38 ft² (3.5 m²) | 26 ft² (2.4 m²) | 20 ft² (1.8 m²) | 14 ft² (1.3 m²) | 11 ft² (1 m²) |
| 8" x 8" x 3/8" (20.3 x 20.3 x 1 cm) | 66 ft² (6.1 m²) | 34 ft² (3.1 m²) | 23 ft² (2.1 m²) | 17 ft² (1.6 m²) | 12 ft² (1.1 m²) | 9 ft² (0.9 m²) |
| 12" x 12" x 3/8" (30.5 x 30.5 x 1 cm) | 98 ft² (9.1 m²) | 50 ft² (4.6 m²) | 34 ft² (3.1 m²) | 25 ft² (2.4 m²) | 17 ft² (1.6 m²) | 13 ft² (1.2 m²) |
| 16" x 16" x 3/8" (40.6 x 40.6 x 1 cm) | 131 ft² (12.1 m²) | 66 ft² (6.1 m²) | 44 ft² (4.1 m²) | 33 ft² (3.1 m²) | 23 ft² (8.5 m²) | 17 ft² (1.6 m²) |
| 18" x 18" x 3/8" (45.7 x 45.7 x 1 cm) | 147 ft² (13.7 m²) | 74 ft² (6.9 m²) | 50 ft² (4.6 m²) | 38 ft² (3.5 m²) | 25 ft² (2.4 m²) | 19 ft² (1.8 m²) |
| 20" x 20" x 3/8" (50.8 x 50.8 x 1 cm) | 163 ft² (15 m²) | 82 ft² (7.6 m²) | 55 ft² (5.1 m²) | 42 ft² (3.9 m²) | 28 ft² (2.6 m²) | 21 ft² (2 m²) |
| 24" x 24" x 3/8" (61 x 61 x 1 cm) | 196 ft² (18 m²) | 98 ft² (9.1 m²) | 66 ft² (6.1 m²) | 50 ft² (4.6 m²) | 34 ft² (3.1 m²) | 25 ft² (2.3 m²) |
| 6" x 24" x 3/8" (15.2 x 61 x 1 cm) | 79 ft² (7.3 m²) | 40 ft² (3.7 m²) | 27 ft² (2.5 m²) | 20 ft² (1.9 m²) | 14 ft² (1.3 m²) | 11 ft² (1 m²) |
| 12" x 24" x 3/8" (30.5 x 61 x 1 cm) | 131 ft² (12.1 m²) | 66 ft² (6.1 m²) | 44 ft² (4.1 m²) | 33 ft² (3.1 m²) | 23 ft² (2.1 m²) | 17 ft² (1.6 m²) |
| 6" x 36" x 3/8" (15.2 x 91.4 x 1 cm) | 85 ft² (7.9 m²) | 43 ft² (4 m²) | 29 ft² (2.7 m²) | 22 ft² (2 m²) | 15 ft² (1.4 m²) | 11.5 ft² (1.1 m²) |
| 9 x 36" x 3/8" (22.9 x 91.4 x 1 cm) | 118 ft² (10.9 m²) | 60 ft² (5.5 m²) | 40 ft² (3.7 m²) | 30 ft² (2.8 m²) | 21 ft² (1.9 m²) | 15.5 ft² (1.4 m²) |
| 12" x 48" x 3/8" (30.5 x 122 x 1 cm) | 157 ft² (14.6 m²) | 79 ft² (7.3 m²) | 53 ft² (4.9 m²) | 40 ft² (3.7 m²) | 27 ft² (2.5 m²) | 20.5 ft² (1.9 m²) |
Chart for estimating purposes. Coverage may vary based on installation practices and jobsite conditions. For more tile and joint sizes, use the Material Calculator at CustomBuildingProducts.com or contact CUSTOM Technical Services at 800-282-8786.
